transformer ttr tester[/caption] [caption id="attachment_555" align="aligncenter" width="700"]

portable transformer ttr tester[/caption]

Auto Turns Ratio Measurement Transformer TTR Tester

Auto Turns Ratio Measurement Transformer TTR Tester provided by by Lucyelec Test Equipment Co., Ltd., is the updated cooling design. Suitable for single/three phase substation power transformer and PT ratio measurement. It has the functions of blind measurement of transformation ratio, group test, tap position test, etc. AC/DC power supply, small size, light weight and easy to carry. At Lucyelec Test Equipment Co., Ltd., we take pride in offering the high-qualified Transformer Turns Ratio Tester. We also call it voltage ratio test. This equipment is designed to provide precise and reliable measurements of transformer turns ratio, making it an essential tool for professionals in the electrical and power industry. For more details, please contact Lucyelec

Description

Auto Turns Ratio Measurement Transformer TTR Tester

Model: TTR-BB101 (Better cooling design, AC Power or with battery inside)

Ⅰ.Brief Introduction of TTR Tester

The power transformer shall be regularly tested for turns ratio or voltage ratio, including semi-finished products and finished products in the production process, transformers before putting into operation and during operation in the power system. The traditional transformation ratio bridge is cumbersome to operate, the reading is not intuitive, the necessary conversion is needed, and the test results only reflect one phase transformation ratio. The instrument overcomes the shortcomings of the traditional transformation ratio bridge test, completes the three-phase transformation ratio test at one time, has fast test speed and high accuracy, and greatly improves the test efficiency.

Advantages: Wide test range up to 10000, Better cooling design, Blind measurement of transformation ratio, group test, tap position test, etc.

transformer TTR measurement

Ⅱ. Technical Parameters of transformer TTR tester

1. Test Range: 0.9~10000

2. Accuracy: 0.1%±2 digit (0.9~500)

0.2%±2 digit (500~2000)

0.3%±2 digit (2000~4000)

0.5%±2 digit (4000 above)

3. Resolution: minimum 0.0001

4. Output Voltage: 160V/10V (Auto shift)

5. Power Supply:

AC mode——External AC power supply AC220V ± 10%, 50Hz is required. (Do not use the generator)

DC mode——No external power supply is required (the instrument has its own lithium battery).

6. Working Temperature: –10℃~40℃

7. Relative Humidity: ≤ 80%, no condensation

Ⅲ. Features and Advantages of turns ratio measurement

At Lucyelec Test Equipment Co., Ltd., we take pride in offering the high-qualified Transformer Turns Ratio Tester. We also call it voltage ratio test. This equipment is designed to provide precise and reliable measurements of transformer turns ratio, making it an essential tool for professionals in the electrical and power industry.

Service: The TTR will be repaired and replaced free of charge for product quality problems within one year from the date of purchase, and will provide lifetime warranty and technical services. If you find any abnormalities or malfunctions in the instrument, please contact the company in time to arrange the most convenient solution for you.
